Certification : UN38.3 MSDS IEC62133 CE ROHS
Model Number : 21700-8000-7.4V
Brand Name : MEISAEN
Payment Terms : T/T
Supply Ability : 100000PCS
MOQ : 1000PCS
Place of Origin : Shenzhen, China
| Parameter | Details |
|---|---|
| Cell Type | 21700 Lithium-Ion |
| Configuration | 2S2P (2 Series, 2 Parallel) |
| Nominal Voltage | 7.4V |
| Nominal Capacity | 8000mAh |
| Rated Energy | 59.2Wh |
| Full Charge Voltage | 8.4V |
| Cut-off Voltage | 6.0V (typical) |
| Connector | 2-Pin Red Connector |
| Dimensions | 42 × 42 × 70.5 mm |
| Protection | Overcharge, Over-discharge, Overcurrent, Short Circuit |
| Operating Temp (Discharge) | -20℃ ~ 60℃ |
| Operating Temp (Charge) | 0℃ ~ 45℃ |

|
|
High Capacity 7.4V 8000mAh 21700 Battery Pack BMS Protected For Outdoor String Lights Images |
