4P Parallel 32700 Lithium Battery 3.2V 24Ah LiFePO4 Battery Pre Welded Module

Our 32700 3.2V LiFePO4 battery module is factory pre-spot welded with four Grade A 6000mAh cylindrical cells in parallel (4P). Total rated capacity reaches 24000mAh (24Ah) under 3.2V nominal voltage. Pre-assembled busbar design saves customers spot welding cost and assembly time, directly available for series combination to build custom battery systems. With reliable LiFePO4 safety features and consistent cell performance, it is a popular choice for off-grid energy storage and DIY power projects.

Product Highlights

1. Factory pre-welded 4P parallel structure: 4pcs 32700 6Ah cells integrated into one module, no extra welding needed.
2. Brand new Grade A LiFePO4 cells with tight consistency on voltage and internal resistance, no used/refurbished cells.
3. Superior safety: Lithium iron phosphate material avoids swelling, fire or explosion risk; ≥3000 full charge cycles.
4. Low self-discharge ≤3% per month, stable output, wide temperature adaptability for indoor and outdoor installation.
5. Easy stacking in series: Combine multiple modules in series to make 12V,24V,48V large-capacity battery packs.

Application Scenarios

• Off-grid solar home energy storage & backup power supply
• Large portable power station, camping, caravan/RV storage battery
• E-bike, low speed vehicle, golf cart DIY battery assembly
• UPS, industrial monitoring equipment, small machine standby power

  Item	Spec
  Model	32700 LiFePO4 4P Parallel Module
  Chemistry	Lithium Iron Phosphate (LiFePO4)
  Nominal Voltage	3.2V
  Single Cell Capacity	6000mAh (6Ah)
  4P Total Capacity	24000mAh (24Ah)
  Cell Dimension	Φ32mm×70mm
  Cell Grade	Grade A New
  Structure	4 Cells Parallel(4P), Pre Spot Welded
  Charge Cut-off	3.65V
  Discharge Cut-off	2.5V
  Standard Charge Current	0.2C = 4.8A
  Max Continuous Discharge	1C = 24A
  Cycle Life	≥3000 Cycles (0.5C,80%DOD)
  Working Temp	Charge:0~45℃｜Discharge:-20~60℃
  Self-discharge	≤3% / Month
